Infusion Speed: Time mode, rate mode
Applicable syringes: Various brands of syringes: 5, 10, 20, 30, 50/60 ml
Injection rate: 5 ml: 0.1 ml/h – 150 ml (0.1 ml/h increment) 10 ml: 0.1 ml/h – 300 ml (0.1 ml/h increment) 20 ml: 0.1 ml/h – 600 ml (0.1 ml/h increment) 30 ml: 0.1 ml/h – 900 ml (0.1 ml/h increment) 50 ml: 0.1 ml/h – 1500 ml (0.1 ml/h increment)
Bolus rate: 5 ml: 0.1-150 ml/h – (default 150 ml) 10 ml: 0.1-300 ml/h – (default 300 ml) 20 ml: 0.1-600 ml/h – (default 600 ml) 30 ml: 0.1-900 ml/h – (default 900 ml) 50 ml: 0.1-1500 ml/h – (default 1500 ml)
Bolus volume infused: Accumulated bolus volume display
Purge rate: 5 ml: 150 ml 10 ml: 300 ml 20 ml: 600 ml 30 ml: 900 ml 50 ml: 1500 ml
KVO: 0.1~3 ml/h
Volume to be infused (VTBI): 0.1 ml~1000 ml
Volume delivered range: 0.1~9999.9 ml
Accuracy: ±2% (mechanical ±1%)
Time mode: Volume limit: 0.1~999.9 ml
Pre-set time: 1 min to 99 h and 99 min
Remaining time: **h **min
Displayed information: Flow rate, volume limit, volume infused, syringe size, pressure value, battery capacity, unit of dosage, AC power indicator, battery charge indicator, bolus rate etc
Occlusion pressure detection: 3 adjustable occlusion pressure settings: low, middle and high 450/750/1050 mmHG
