Dimensions
– Table top including head support: 300x140cm or 280x140cm
– Head support of the table: 40x85cm or 30x85cm
– Table width excluding side panels: 50cm
– Side panels – table 46x37cm
– Side panels – head support 30x50cm
– Wheels: Ø15 cm
– Padding thickness: 5cm
– Weight :550 kg
Adjustability
– Minimum height: 34 cm
– Maximum height: 110 cm
– Pelvic angle: +/-25°
– Head support angle: +/-25°
– Lateral angle: +/-12°
Features
– Removable Head support sides
– Removable Side panels
– Removable Control buttons in front both sides
– Loading Maximum load: 1300 kg
– Two speed lift :
Lifting time normal (35 sec)
Lifting time fast for unloaded table (15 sec)
Electric equipment Operation
– voltage: – 12 V Battery Service free lead acid cyclic application 12 V 38 Ah ,10 years
– Automatic battery charger output: 12 V 10 A
– Charger input : 110 V / 240 V AC / 50-60 Hz
Battery charging time: 6 hrs
Full battery: ca.30 lifts
Wireless remote control Readiness for transport unit Table can be used during charging
Surface coating AL oxide blast, double paint
3 Year General Warranty
5 Year Frame Warranty
Spare part delivery guarantee is 20 years
